Suspended single-layer Graphene
Single-layer Graphene is suspended on microchannels fabricated on Si/SiO2 substrate.
Scanning Conditions
- System: NX20
- Scan Mode: Non-contact
- Cantilever: Access-NC (k=113N/m, f=330kHz)
- Scan Size: 40μm×40μm
- Scan Rate: 0.4Hz
- Pixel Size: 256 × 256
- Scan Mode: Non-contact
- Cantilever: Access-NC (k=113N/m, f=330kHz)
- Scan Size: 40μm×40μm
- Scan Rate: 0.4Hz
- Pixel Size: 256 × 256
