Graphene on hBN
Scanning Conditions
- System : FX40
- Sample bias: 1 V
- Scan Mode: C-AFM
- Scan Rate : 25 Hz for 25 nm2, 10 Hz for 50 nm2
- Scan Size : 25nm2×25nm2
- Pixel Size : 128×128 for 25 nm2, 256×256 for nm2
- Cantilever : ElectricMulti75-G (k=3N/m, f=75kHz)
