Pattern in Microchannel
Patterns are used to reduce liquid flow speed in microchannel.
Scanning Conditions
- System: NX10
- Scan Mode: Non-contact
- Cantilever: AC160TS (k=26N/m, f=300kHz)
- Scan Size: 3μm×3μm, 5μm×5μm
- Scan Rate:1Hz, 0.5Hz
- Pixel: 512×256, 512×256
- Scan Mode: Non-contact
- Cantilever: AC160TS (k=26N/m, f=300kHz)
- Scan Size: 3μm×3μm, 5μm×5μm
- Scan Rate:1Hz, 0.5Hz
- Pixel: 512×256, 512×256
