Li ion battery electrode
Scanning Conditions
- System: NX-Hivac
- Scan Mode: SSRM
- Cantilever: CDT-NCHR (k=80 N/m)
- Scan Size: 50μm×50μm, 5μm×5μm
- Scan Rate: 1Hz, 1Hz
- Pixel: 4096×2048, 512×512
