Kevlar fiber
Scanning Conditions
- System: XE7
- Scan Mode: NCM, F/D mapping
- Cantilever: Diamond probe(k=151N/m, f=50kHz)
- Scan Size:15μm×15μm
- Scan Rate: 0.5Hz
- Pixel: 512×256
- Scan Mode: NCM, F/D mapping
- Cantilever: Diamond probe(k=151N/m, f=50kHz)
- Scan Size:15μm×15μm
- Scan Rate: 0.5Hz
- Pixel: 512×256
